Comparison between Shima Seiki 7GG and Stoll Machine 3GG

SL	Topics	Shima Seiki	Stoll
1	Knitting Speed	1.20 m/s	1.20 m/s
2	Broken Needle	25%	20%
3	Oiling	Every 8 to 12 operating hour run 20 gm oil need for one machine	Every 12 operating hour run 35 gm oil need for one machine
4	Cleaning	Every 8 to 12 operating hour should be cleaning	Every 12 operating hour should be cleaning
5	Spare Parts	Payment after delivery	Payment before delivery
6	Feeder Quantity	9 Feeder (Limitation of knit 7 different colors)	12 Feeder (Limitation of knit 10 different colors)
7	Sub Roller Quantity	One Sub Roller	Two Sub Roller (Increase production quality)
8	Needle Price	75 Tk	143 TK
9	Weight	660 Kg	1028 Kg
10	Cone Stands	Travelled in Top Bed	Fixed in Top bed
11	Knitting Bed	45 inch	45 inch
12	Power Consumption	1.28 KW	1.7 KW
13	Length	7.054 ft	7.8 ft
14	Width	2.58 ft	3 ft
15	Needle Quantity	630 Pcs	448 Pcs
16	Model	SSR112 (Gauge: 7G)	CMS 502 HP+ Multigauge (Gauge: E2,5.2 M, 4L)
